Description
Features
1500 W fog machine with LED illumination, vertical & horizontal operation
- Output nozzle with RGBA LED illumination for impressive effect presentations
- New housing design allows upward and downward fog output
- Adjustable timer with interval, duration and output volume
- Continuous output
- Rugged metal housing
- Output distance: Horizontal approx. 12 m
- Output distance: Vertical approx. 10 m
- 15 integrated show programs
- Direct color selection for 10 preset colors
- Control via stand-alone; timer; DMX; wireless remote control; W-DMX by wireless solution upgradeable
- Wireless remote control: operating range up to 50m
- Built with NEUTRIK connector
- For application areas such as: Mobile use; stage; theater; rental
- With level indication
- Operates on water-based fluid
- Removable tank
- Monochrome LCD display
- Application possibility: Standing
Package contents
- 1 x remote control, 1 x device, 1 x power cord, 1 x declaration of conformity, 1 x container, 2 x tube, 1 x user manual, 1 x battery
Technical specifications
| Power supply: | 230 V AC, 50 Hz |
| Power consumption: | 1450 W |
| IP classification: | IP20 |
| Protection class: | Protection class I |
| Power connection: | Mains input via PowerCON TRUE (M) mounting version power supply cord with safety plug (provided) |
| Warm-up time: | Approx. 8 min |
| Output distance: | Vertical approx. 10 m Horizontal approx. 12 m |
| Tank capacity: | 2,4 l water-based fluid removable tank |
| Fluid consumption: | Approx. 130 ml/min |
| DMX channels: | 9 |
| DMX input: | 1 x 3-pin XLR (F) mounting version 1 x 5-pin XLR (F) mounting version |
| DMX output: | 1 x 3-pin XLR (M) mounting version 1 x 5-pin XLR (M) mounting version |
| Control: | Stand-alone; timer; DMX; wireless remote control; W-DMX by wireless solution upgradeable |
| Range: | Wireless remote control: range up to 50m |
| Carrier frequency: | 433,92 MHz |
| Housing color: | Black |
| Display type: | Monochrome LCD display |
| Use of brands: | Built with NEUTRIK connector |
| Color: | Black |
| Dimensions: | Width: 19,3 cm Depth: 34,4 cm Height: 38,1 cm |
| Weight: | 14,25 kg |
| Noise classification: | Class 3 (clearly perceptible sounds) |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4719850654023 | 15,35 kg | 41cm x 29cm x 46,5cm |
