EUROLITE ESX-4R DMX RDM Switch Pack

 125,00 excl. VAT

4-channel DMX switch pack, up to 5 A load per channel, control per Triac

SKU: 70064224 Category: Tag:

Description

Features

4-channel DMX switch pack, up to 5 A load per channel, control per Triac

  • 4 controllable channels
  • 5 A load per channel
  • LED display of all channels
  • With Control Board for programming scenes and chasers
  • Rugged metal housing
  • Control via stand-alone; DMX; RDM
  • 4 digit 7-segment LED display
  • For application areas such as: Clubs/dancing school; party room; theater; restaurants, bars and hotels
  • Silent operation

Package contents

  • 1 x device, 1 x user manual

Technical specifications

Power supply: 230 V AC, 50 Hz
Output power: Max. 3680 W; max. 1150 W per channal
Output current: Max. 16 A
Power connection: Fixed power supply cord with safety plug
Power output: 4 x safety contact (F), mounting version
DMX channels: 4
DMX input: 3-pin XLR (M) mounting version
DMX output: 1 x 3-pin XLR (F) mounting version
Control: Stand-alone; DMX; RDM
Control channels: 4
Display type: 4 digit 7-segment LED display
Color: Black
Dimensions: Width: 27 cm
Depth: 26 cm
Height: 9,5 cm
Weight: 2,83 kg
Noise classification: Class 0 (no noise at all)
Packaging units
PU EAN Weight Dimensions
1 4026397473407 3,40 kg 33cm x 33cm x 19cm

Additional information

Weight 3,40 kg
Dimensions 33 × 33 × 19 cm
Brand

EUROLITE
