Description
Features
Basic DMX controller for 6 channels with master fader
- Basic DMX controller for convenient operation of light effect units with DMX512 interface (e.g. spotlights and dimmers)
- 6 channel faders for adjusting the DMX values
- 1 master fader
- Compact design
- Powered by a battery/battery pack
- Can transmit up to 6 DMX channels
- Desktop console housing
- For application areas such as: Trade fair and shop fitting; restaurants, bars and hotels; video and photography
- Silent operation
Package contents
- 1 x controller, 1 x user manual, 1 x external mains adapter
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz 9 V DC |
| Power consumption: | 1,8 W |
| IP classification: | IP20 |
| Protection class: | Protection class III |
| Power connection: | Mains input via coaxial power connector (M) mounting version power supply cord with AC adapter (provided) Battery/battery pack possible |
| Battery: | 1 x 9.0 V E block (not included) |
| DMX channels: | Output 6 |
| DMX output: | 3-pin XLR (F) mounting version |
| Housing color: | Black |
| Housing design: | Desktop console housing |
| Dimensions: | Width: 17 cm Depth: 15,5 cm Height: 6 cm |
| Weight: | 960 g |
| Noise classification: | Class 0 (no noise at all) |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397568035 | 1,10 kg | 29cm x 19cm x 10cm |
