Description
Features
3in1 LED effect light with RGB color mixing and DMX
- 140 powerful LEDs 3 W SMD 3535 cold white (CW)
- 672 powerful LEDs 0,2 W SMD 5050 3in1 TCL RGB (homogenous color mix)
- Strobe effect; wash effect; Blinder effect
- 37 integrated show programs
- The device is cooled by cooling fan
- Control via stand-alone; DMX; master/slave function
- Flicker-free
- With mounting bracket
- LCD display
- Dimmer curves adjustable; color blend stepless; Dimmer electronic
- Preprogrammed in Light Captain
- For application areas such as: Clubs/dancing school; wedding/gala/events; stage; mobile djs / entertainer; rental
- Very quiet working noise
- Application possibility: Suspended; on stand
Package contents
- 1 x light effect, 1 x user manual, 1 x power cord
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 400 W |
| IP classification: | IP20 |
| Protection class: | Protection class I |
| Power connection: | Mains input via P-Con (blue), mounting version (provided) |
| Power output: | 1 x P-Con (gray), mounting version |
| Fuse: | T 3 A fuse replaceable |
| LED type: | 140 x 3 W SMD 3535 cold white (CW) 672 x 0,2 W SMD 5050 3in1 TCL RGB (homogenous color mix) |
| Flash rate: | 1 – 30 Hz |
| DMX channels: | 6; 17; 20; 21; 298; 310 |
| DMX input: | 5-pin XLR (M) mounting version 3-pin XLR (M) mounting version |
| DMX output: | 5-pin XLR (F) mounting version 3-pin XLR (F) mounting version |
| Cooling: | Cooling fan |
| Control: | Stand-alone; DMX; master/slave function |
| Preprogrammed in: | Light Captain |
| Projection: | Flicker-free |
| Beam angle (1/2 peak): | 120° |
| Attachment system: | Mounting bracket |
| Display type: | LCD display |
| Dimensions: | Width: 50,0 cm Depth: 14,5 cm Height: 27,5 cm |
| Weight: | 7,45 kg |
| Noise classification: | Class 1 (very slight noise, suitable for noise-sensitive environments) |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397707595 | 8,20 kg | 52cm x 22cm x 34cm |
