EUROLITE LED PLL-432 CW/WW Panel

 399,00 excl. VAT

DMX-controlled surface light with 432 dual white LEDs, QuickDMX port and barn doors

SKU: 40001894 Category: Tag:

Description

Features

DMX-controlled surface light with 432 dual white LEDs, QuickDMX port and barn doors

  • 432 powerful LEDs SMD 2835 CW/WW
  • 4 barn doors to avoid blinding the audience and for protection during transport
  • Energy-saving, durable and environmentally friendly
  • Variable color temperature 2800 K – 6500 K
  • Pulse-width modulation variable
  • Strobe effect
  • Integrated show programs
  • The device is cooled by passive convection cooling
  • Control via DMX; quick select potentiometer for brightness and color temperature; stand-alone; sound to light via microphone; master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
  • Flicker-free
  • With a beam angle of 120°
  • Very high color rendering index (CRI)
  • With mounting bracket
  • LCD display
  • For application areas such as: Video and photography; stage; Trade fair and shop fitting; installation
  • Preprogrammed in Light Captain
  • Mains input and output for power linking up to 8 units
  • Rugged carrying handle
  • Silent operation
  • Application possibility: Suspended; on stand

Package contents

  • 1 x spotlight, 1 x user manual, 1 x power cord

Technical specifications

Power supply: 100-240 V AC, 50/60 Hz
Power consumption: 85 W
IP classification: IP20
Protection class: Protection class I
Fuse: T 3 A fuse replaceable
Lamp type: LED lamp
LED type: 432 x SMD 2835 CW/WW
DMX channels: 2; 4; 6
DMX input: 3-pin XLR (M) mounting version
DMX output: 3-pin XLR (F) mounting version
Cooling: Passive convection cooling
Control: DMX; quick select potentiometer for brightness and color temperature; stand-alone; sound to light via microphone; master/slave function; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
Preprogrammed in: Light Captain
Projection: Flicker-free
Beam angle: 120°
Beam angle (1/2 peak): 120°
Color temperature: 2800K – 6500K adjustable
Color rendering index (CRI): 91 Ra
Illuminance in Lux (lx): Cold white (CW) 1m: 919 lx, 3m: 124 lx, 6m: 38 lx
Warm white (WW) 1m: 801 lx, 3m: 109 lx, 6m: 33 lx
All 1m: 1681 lx, 3m: 228 lx, 6m: 69 lx
Housing color: Black
Attachment system: Mounting bracket
Display type: LCD display
Carrying handle: 1 pc/pcs
Dimensions: Width: 60,3 cm
Depth: 17,9 cm
Height: 20,8 cm
Weight: 4,60 kg
Noise classification: Class 0 (no noise at all)
Photobiological safety: Risk Group 0
Packaging units
PU EAN Weight Dimensions
1 4026397700718 5,15 kg 62cm x 17cm x 24cm

Additional information

Weight 5,15 kg
Dimensions 62 × 17 × 24 cm
Brand

EUROLITE
