Description
FUTURELIGHT DMH-640:
Powerful LED moving spotlight
With the DMH-640, Futurelight offers an LED moving spotlight that impresses in terms of performance and features. This versatile device is suitable for a wide range of applications, from live concerts to theater productions.
Features
The DMH-640 has a 640-watt LED that provides high light output. With CMY color mixing, frost filter and two gobo wheels, the DMH-640 offers a wide range of creative possibilities.
The CMY color mixing enables smooth color transitions and an almost unlimited selection of colors. In addition, the gobo wheels create impressive visual effects that give every show that certain something.
Shutter sliders and zoom
Four motorized shutters can precisely limit the light by means of retractable and rotatable shutters, which is particularly advantageous for theatrical applications. The zoom range extends from 10° to 47°, allowing the DMH-640 to be used flexibly for various lighting scenarios: from narrow beams to wide wash effects.
Application
The DMH-640 is designed for use in fog as well as for projections. When selecting the gobos, care was taken to ensure that both impressive projections and clear structures in the fog are possible. With its CRI filter and very quiet operation, the moving head is therefore a good choice for a wide range of applications, including live events, theater productions and installations.
Connections
The DMX connections are both 3-pin and 5-pin, allowing flexible integration into existing lighting systems.The power connection is made via T-Con.
Features
Profile moving head with 640 W COB LED, motorized shutter blades, large zoom, CMY+CTO color mixing and animation wheel
- 1 powerful LED 640 W COB (chip-on-board) cold white (CW)
- Positioning within 540° PAN, 260° TILT
- Auto position correction (feedback)
- Exact positioning (16 bit resolution)
- Exact 16 bit resolution at Dimmer, zoom, focus, gobo rotation
- Prism 4-fold rotating; iris; frost filter linear; zoom motor driven; focus motor-driven; animation wheel; shutter blades motor-driven
- Pulse-width modulation variable
- CMY+CTO color mixing for indefinite color variations
- Color wheel with 8 dichroic filters plus open
rainbow effect with adjustable speed in both directions - Gobo wheel with rotating gobos, 7 gobos and open
shake effect - Gobo indexable
- Slot-in gobo system for easy gobo replacement
- Gobo wheel with static gobos, 8 gobos and open
shake effect - The device is cooled by temperature-controlled fan at the Head; temperature-controlled fan at the base
- Control via stand-alone; master/slave function; DMX; RDM; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); CRMX by LumenRadio upgradeable; W-DMX by wireless solution via USB (optional)
- Flicker-free
- With a beam angle of 10° – 47°
- Good color rendering index (CRI)
- With omega bracket
- Multicolor LCD display,
with battery buffering for easy controlling upgradeable - For application areas such as: Wedding/gala/events; stage; theater; rental
- Very quiet working noise
- Application possibility: Standing; suspended
Package contents
- 1 x moving light, 1 x user manual, 1 x power cord, 2 x omega bracket, 1 x XLR cable
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 750 W |
| IP classification: | IP20 |
| Protection class: | Protection class I |
| Power connection: | Mains input via IP T-Con (M) mounting version power supply cord with safety plug |
| Device fuse: | 6.3 x 32 mm, 5 A fuse replaceable |
| Lamp type: | LED lamp |
| LED type: | 1 x 640 W COB (chip-on-board) cold white (CW) |
| Max. TILT movement: | 260° exact positioning (16 bit resolution) auto position correction (feedback) |
| Max. PAN movement: | 540° exact positioning (16 bit resolution) auto position correction (feedback) |
| Flash rate: | 1 – 16 Hz |
| Equipment: | Prism 4-fold rotating; iris; frost filter linear; zoom motor driven; focus motor-driven; animation wheel; shutter blades motor-driven |
| Color generation: | CMY+CTO color mixing for indefinite color variations |
| Color generation: | Color wheel with 8 dichroic filters plus open Rainbow effect with adjustable speed in both directions |
| Gobos: | Gobo wheel with rotating gobos, 7 gobos and open Outside diameter 30mm Image diameter 22mm Shake effect Gobo indexable Slot-in gobo system for easy gobo replacement Gobo wheel with static gobos, 8 gobos and open Shake effect |
| DMX channels: | 33; 35; 39 |
| DMX input: | 5-pin XLR (M) mounting version IP 3-pin XLR (M) mounting version IP |
| DMX output: | 5-pin XLR (F) mounting version IP 3-pin XLR (F) mounting version IP |
| Cooling: | 4 x temperature-controlled fan at the Head 2 x temperature-controlled fan at the base |
| Control: | Stand-alone; master/slave function; DMX; RDM; QuickDMX via USB (optional); CRMX by LumenRadio via USB (optional); CRMX by LumenRadio upgradeable; W-DMX by wireless solution via USB (optional) |
| Projection: | Flicker-free |
| Beam angle: | 10° – 47° |
| Beam angle (1/2 peak): | 10 – 47° |
| Beam angle (1/10 peak): | 10 – 47° |
| Color rendering index (CRI): | 85 Ra via filter |
| Illuminance in Lux (lx): | Narrow cold white (CW) 3m: 69565 lx, 6m: 19180 lx Wide cold white (CW) 1m: 27924 lx, 3m: 3489 lx, 6m: 1000 lx |
| Housing color: | Black |
| Attachment system: | 2x omega bracket |
| Display type: | Multicolor LCD display battery buffering upgradeable |
| Dimensions: | Width: 44,2 cm Depth: 30,1 cm Height: 75,3 cm |
| Weight: | 37,15 kg |
| Noise classification: | Class 1 (very slight noise, suitable for noise-sensitive environments) |
| Legal specifications | |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397726534 | 41,00 kg | 86cm x 54cm x 42cm |
