Description
Futurelight DMH-80
PRO Moving Head with 75 Watts LED and unique 16-fold prism
The Futurelight DMH 80 is equipped with a 75 watt LED, which provides a good light output – for a rather small moving head, it is even more than remarkable.
GOBO WHEEL AND 16 FACET PRISM
The gobo wheel offers you 7 different images, which you can easily exchange for individual designs. A particularly beautiful effect is the 16 facet prism. It multiplies the image and generates additional movement through its rotation.
BEAM ANGLE
The beam angle can be set manually between 10° and 16°. You can adapt the spot to the respective room this way. More than 8 dichroic color filters provide for colored accents. The DMH-80 is your ideal solution for clubs and stages that need smaller devices, but do not want to do without professionalism.
Features
PRO moving head with 75 W LED and unique 16-facet prism
- High PAN/TILT speed
- Number of scenes can be changed individually
- The scenes can be modified via the Control Board or via an external controller and loaded into the memory
- 1 powerful LED 75 W COB (chip-on-board) cold white (CW)
- Positioning within 540° PAN, 270° TILT
- PAN angle switchable between 540° and 630°
- Auto position correction (feedback)
- Exact positioning (16 bit resolution)
- Gobo wheel with rotating gobos; prism 16-fold rotating; focus motor-driven
- Gobo effect; beam effect; strobe effect
- Color wheel with 8 dichroic filters plus open
half colors selectable, Rainbow effect with adjustable speed in both directions - Gobo wheel with rotating gobos, 7 gobos and open
shake effect - Gobos changeable
- Slot-in gobo system for easy gobo replacement
- The device is cooled by temperature-controlled fan
- Control via stand-alone; DMX; RDM; sound to light via microphone
- With a beam angle of 10° – 16°
- Multicolor LCD display
- Dimmer electronic
- Preprogrammed in LED PC-Control 512; Light Captain
- For application areas such as: Clubs/dancing school; wedding/gala/events; mobile djs / entertainer; stage
- Application possibility: Standing; suspended
Package contents
- 1 x moving light, 1 x user manual, 1 x power cord, 1 x declaration of conformity, 1 x XLR cable, 1 x omega bracket
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 135 W |
| IP classification: | IP20 |
| Power connection: | Mains input via PowerCON (blue), mounting version power supply cord with safety plug (provided) |
| Power output: | 1 x PowerCON (gray), mounting version |
| Lamp type: | LED lamp |
| LED type: | 1 x 75 W COB (chip-on-board) cold white (CW) |
| Max. TILT movement: | 270° exact positioning (16 bit resolution) auto position correction (feedback) |
| Max. PAN movement: | 540°, 630° exact positioning (16 bit resolution) auto position correction (feedback) |
| Equipment: | Gobo wheel with rotating gobos; prism 16-fold rotating; focus motor-driven |
| Color generation: | Color wheel with 8 dichroic filters plus open Half colors selectable, Rainbow effect with adjustable speed in both directions |
| Gobos: | Gobo wheel with rotating gobos, 7 gobos and open Outside diameter 24mm Image diameter 19mm Shake effect Gobos changeable Slot-in gobo system for easy gobo replacement |
| DMX channels: | 11; 13; 17; 18 |
| DMX input: | 1 x 5-pin XLR (M) mounting version |
| DMX output: | 1 x 5-pin XLR (F) mounting version |
| Cooling: | Temperature-controlled fan |
| Control: | Stand-alone; DMX; RDM; sound to light via microphone |
| Preprogrammed in: | LED PC-Control 512; Light Captain |
| Beam angle: | 10° – 16° |
| Beam angle (1/2 peak): | 10 – 16° |
| Beam angle (1/10 peak): | 10 – 16° |
| Illuminance in Lux (lx): | Narrow cold white (CW) 3m: 8334 lx, 6m: 2169 lx Wide cold white (CW) 3m: 5211 lx, 6m: 1339 lx |
| Housing color: | Black |
| Display type: | Multicolor LCD display |
| Dimensions: | Width: 29,9 cm Depth: 25,2 cm Height: 39,8 cm |
| Weight: | 9,55 kg |
| Noise classification: | Class 2 (slight noise) |
| Legal specifications | |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397620146 | 11,15 kg | 53cm x 37,5cm x 27,5cm |
