Description
Futurelight WDR USB Wireless DMX Receiver
Wireless DMX at the highest level.
Futurelight’s WDR is a very user-friendly wireless DMX receiver that uses LumenRadio’s professional CRMX technology.
Easy to use
The small device is simply connected via USB to a spotlight, lighting effect device or moving head, allowing it to receive wireless DMX signals. Thanks to the CRMX technology used by LumenRadio, these can originate from the professional standards of LumenRadio or Wireless Solution.
Interference-free transmission
Thanks to the built-in frequency hopping, the WDR ensures interference-free signal transmission in the 2.4 GHz band. The LED indicator on the receiver makes it easy to see whether a transmitter is currently connected and a DMX signal is being transmitted.
High range
With visual contact, distances of up to 600 m can be bridged with the WDR. The swiveling antenna makes it possible to align the receiver in the best possible way.
Features
Wireless miniature DMX receiver with LumenRadio technology, 2.4 GHz
- User-friendly USB plug with swivel antenna
- Can be used with all EUROLITE/FUTURELIGHT fixtures with WirelessDMX USB port
- Adaptive frequency hopping ensures interference-free operation in the 2.4 GHz band
- LED indicator for monitoring the operating status
- Can receive and process up to 512 DMX channels
- Control via W-DMX by wireless solution; CRMX by LumenRadio; plug and play
- Operating range up to 600m with line-of-sight
Package contents
- 1 x USB stick, 1 x user manual, 1 x declaration of conformity
Technical specifications
| IP classification: | IP20 |
| Power connection: | Mains input via USB A (M) connectable version |
| DMX channels: | Input 512 |
| DMX output: | USB, type A |
| Phantom power: | Or 5 V DC |
| Control: | W-DMX by wireless solution; CRMX by LumenRadio; plug and play |
| Range: | Range up to 600m with line-of-sight |
| Carrier frequency: | 2,4 GHz |
| Modulation: | AFHSS |
| Color: | Black |
| Dimensions: | Length: 8,6 cm Width: 4,1 cm Height: 1,1 cm |
| Weight: | 20 g |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4026397702453 | 0,06 kg | 9cm x 6cm x 2cm |
