Description
Features
Pure diode laser system
- Control via DMX; stand-alone; sound to light via microphone; ILDA; master/slave function
- The device is cooled by cooling fan
- 4 digit 7-segment LED display
- For application areas such as: Clubs/dancing school
- Application possibility: Suspended
Package contents
- 1 x laser, 1 x user manual, 1 x power cord, 1 x Interlock, 1 x key
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 200 W |
| IP classification: | IP4X |
| Protection class: | Protection class I |
| Power connection: | Mains input via P-Con (blue), mounting version power supply cord with safety plug |
| Power output: | 1 x P-Con (gray), mounting version |
| Laser class: | 4 |
| Laser color: | R/G/B |
| Laser module: | Red (R) 2600 mW 638nm Green (G) 2900 mW 520nm Blue (B) 5500 mW 450nm |
| Cooling: | Cooling fan |
| Control: | DMX; stand-alone; sound to light via microphone; ILDA; master/slave function |
| Housing color: | Black |
| Display type: | 4 digit 7-segment LED display |
| Dimensions: | Length: 28,5 cm Width: 18 cm Height: 19 cm |
| Weight: | 7,80 kg |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 7640144996031 | 8,90 kg | 45cm x 31,5cm x 25,5cm |
