Description
Features
Diode showlaser with ShowNET network interface and free software
- Full color mixing laser with analog color modulation
- Integrated show programs
- Control via master/slave function; stand-alone; Art-Net; ILDA; DMX
- With mounting bracket
Package contents
- 1 x laser, 1 x user manual, 1 x power cord, 2 x key, 1 x Interlock, 1 x bag, 1 x network cable
Technical specifications
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 80 W |
| Protection class: | Protection class I |
| Power connection: | Mains input via IP T-Con (M) mounting version power supply cord with safety plug |
| Power output: | 1 x IP T-Con (F) mounting version |
| Laser class: | 4 |
| Laser color: | R/G/B |
| Laser module: | Blue (B) 1600 mW 450nm Green (G) 900 mW 520nm Red (R) 650 mW 638nm |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Control: | Master/slave function; stand-alone; Art-Net; ILDA; DMX |
| Housing color: | Black |
| Attachment system: | Mounting bracket |
| Dimensions: | Length: 21,0 cm Width: 21,5 cm Height: 14,2 cm |
| Weight: | 5,70 kg |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 7640144997571 | 6,70 kg | 36cm x 36cm x 21cm |
