Description
MADRIX STELLA
The 2-port network node with RDM support for solid-state projects
MADRIX STELLA is all about rock-solid performance.
MADRIX STELLA is a dedicated control interface for DMX512 and Art-Net or Streaming ACN that is designed for high quality and practicability in permanent LED installations.
MADRIX STELLA makes sure that your DMX fixtures reliably light up with vivid colors and smooth animations. It syncs across ports and different devices to make sure the lighting always looks amazing.
Plus, MADRIX STELLA supports Remote Device Management. That means that it is no longer only about sending out control data; devices now respond. This enables unprecedented possibilities for remote configuration and real-time monitoring.
Art-Net / Streaming ACN / USB
Art-Net or Streaming ACN data is directly converted to DMX512. Optimize and decentralize cabling to cover any distance to the device using Ethernet network. In addition, you can simply connect MADRIX STELLA to MADRIX 5 over USB.
2 DMX-IN/OUT
Directly connect DMX512 to the two 3-pin screw terminals to distribute 2 DMX universes per unit as input and/or output, thereby eliminating the need for XLR connectors. Simply use several units at the same time for larger projects.
Easy Configuration
MADRIX STELLA offers powerful features. Nevertheless, managing the device is quick and easy. Just supply power over USB or 5 V to 24 V over a 2-pin screw terminal.
Sync Mode
MADRIX 5 and MADRIX hardware allow you to fully synchronize Art-Net data for all output ports and across multiple devices to get an optimal image on the LEDs without visual interruptions.
3rd-Party Controllers
MADRIX STELLA complies with official protocol specifications and can be used as a regular node with your other consoles, controllers, or software solutions.
RDM & Daisy-Chain Support
2 Ethernet ports allow for separate network connections as well as linearly daisy-chaining several devices together. On top, the device supports the Remote Device Management standard.
Designed For DIN Rails Or Walls
Its non-conductive enclosure and standardized design for 35 mm top-hat rails make mounting quick, easy, and safe. 2 extra brackets are provided for optional wall mounting. 9 indicators quickly show the device status with the option to turn them off.
Upgradable Firmware
The device is ready within seconds after startup. HTP merging is automatically available for two Ethernet sources. Its firmware is upgradable. Access and change specific device settings using the built-in web configuration page.
Connectivity
- • 2x DMX-IN/OUT (via pluggable screw terminals)
- • 2x RJ45 Ethernet ports
- • 1x USB port
- • 1x Power (via pluggable screw terminal)
Package Contents
- • 1x MADRIX STELLA
- • 1x Set of screw terminals (2x 3-pin and 1x 2-pin)
- • 1x USB 2.0 cable (certified)
- • 2x Wall-mount brackets
- • 1x Technical manual / quick start guide
Features
USB and Art-Net interface to control two DMX universes with MADRIX
- Can transmit up to 1024 DMX channels
- The device is cooled by passive convection cooling
- Control via DMX; RDM; Art-Net
- The device can be connected via USB to the PC
- Made in Germany
- For application areas such as: Clubs/dancing school; Trade fair and shop fitting; installation; restaurants, bars and hotels; architecture
- For further information about this product, please refer to the Data Sheet under “Downloads”
Technical specifications
| Power supply: | 5-24 V AC |
| IP classification: | IP20 |
| Power connection: | Mains input via USB, type B power supply cord for USB A mains connection (provided) |
| DMX channels: | Output 1024 |
| Network connection: | Protocol: Art-Net 1,2,3,4 incl. ArtSync via 2x RJ-45 (F) mounting version, 10/100/1000 Mbit/s Protocol: Streaming ACN (sACN / ANSI E1.31) via 2x RJ-45 (F) mounting version, 10/100/1000 Mbit/s |
| Cooling: | Passive convection cooling |
| Control: | DMX; RDM; Art-Net |
| USB port: | USB 2.0, type B |
| PC connect: | Via USB |
| Dimensions: | Width: 7 cm Depth: 9,2 cm Height: 4,5 cm |
| Weight: | 370 g |
Packaging units
| PU | EAN | Weight | Dimensions |
|---|---|---|---|
| 1 | 4260263421196 | 0,55 kg | 22,5cm x 16,5cm x 7,5cm |
